Industrial Diamond Grinding Wheels Boomerang
Description
Technical Parameters
Industrial Diamond Grinding Wheels Boomerang – Boomerang-shaped segments increase contact area for faster, more stable concrete leveling and stone grinding.
The "Boomerang" grinding wheel takes its name from its segment shape – boomerang-shaped segments. This is a distinctive design among diamond cup wheels, different from common turbo, single-row, or double-row configurations.
What problem does the boomerang shape solve?
Standard cup wheels have point or line contact with the floor – small contact area, prone to bouncing, unstable, and less efficient. The boomerang shape, with its curved arc design, significantly increases the contact area between the wheel and the floor. Larger contact area means more stable, smoother grinding – no bouncing, more uniform finish.
Main applications:
Concrete leveling – Grind down bumps, laitance, and uneven spots
Surface preparation – Base preparation for epoxy and densified floors
Stone grinding – Surface finishing on granite, marble, and natural stone
Edge blending and deburring – Edge smoothing and finishing
Coating removal – Strip thin-set mortar and adhesive residues
Compatible equipment: Angle grinders (100mm/115mm/125mm/150mm/180mm). Arbor sizes: 22.23mm (7/8″) and 19mm. Works dry or wet. As a source factory, we support full customization: diameter, grit, bond hardness, arbor size.
This is the core question for the Boomerang wheel. Direct comparison:
| Feature | Single Row | Double Row | Turbo | Boomerang (ours) |
|---|---|---|---|---|
| Contact area | Small | Medium | Medium | Large |
| Stability | Fair (bounces) | Good | Good | Excellent (no bounce) |
| Grinding speed | Fast | Medium | Fast | Fast |
| Surface finish | Fair (marks) | Good | Good | Excellent (uniform) |
| Chip evacuation | Fair | Medium | Good | Good (open slots + large holes) |
| Ease of use | Needs skill | Medium | Medium | Low (stable, beginner-friendly) |
Three unique advantages of boomerang segments:
① Large contact area: The curved arc design gives much larger contact surface than standard segments. No bouncing – even beginners can grind flat.
② Open slots + large cooling holes: Wide gaps between segments, large holes in the cup body – heat and dust evacuate quickly. No clogging, no overheating.
③ Fast speed + uniform finish: Large contact area means high material removal, but without leaving uneven marks.
Materials: Concrete (new/old), cement screed/leveling compounds, masonry, natural stone (granite, marble), blocks.
Works dry and wet.
For dry grinding, the open slot design plus large cooling holes allow air circulation – less overheating. Wet grinding with water cools faster, suppresses dust, and extends life.
Dry or wet?
Indoor, dust-sensitive → wet
Outdoor, no water, small patches → dry
Large-area continuous work → wet (longer life)
Application: Widely used in various applications, ranging from general concrete preparation, coating/glue removal to concrete grinding and polishing.
The long segments help keep the tool flatter on the ground and reduce gouging. Available in a variety of grits, these versatile segments are used for general preparation of concrete to finer grit grinding for polishing or thin coatings.
Customized size please consult Diaflex for feasibility.
Diaflex's diamond saw blades are suitable for high rotation speed automatic cutting equipment, with long lifespan, low replacement frequency and better safety.
The blade can fully play the advantage of automatic cutting equipment, therefore reduce labor cost and ensure personal safety.
